GitLab version tags

Open in ChatGPTOpen in Claude

Tell Coralogix when a new build ships, straight from your GitLab deployment pipeline. A pipeline webhook creates a version tag, which is what version benchmark reports compare behavior across.

What you need

• Access to your GitLab project's settings.
• A personal or team API key with the CICDIntegration preset. Presets pick up new permissions automatically; individual permissions have to be maintained by hand.
• The GitLab version tags endpoint for your Coralogix domain. Use the domain selector at the top of this page to resolve it: https://api./api/v1/external/gitlab

Preset	Actions	Grants
CICDIntegration	VERSION-BENCHMARK-TAGS:READ VERSION-BENCHMARKS-REPORTS:READ VERSION-BENCHMARK-TAGS:UPDATE	View version benchmark tags View version benchmark reports Modify version benchmark tags

Add the webhook in GitLab

1.

Open the webhook settings

Sign in to GitLab, open your project, then select Settings, then Webhooks.

2.

Enter the URL

Build the URL from the GitLab endpoint for your domain and the query parameters below.

https://api.eu2.coralogix.com/api/v1/external/gitlab?application=APPLICATION_NAME&subsystem=SUBSYSTEM_NAME&name=TAG_NAME

Parameter	What to enter
application	Application name as it appears in your Coralogix UI
subsystem	Subsystem name as it appears in your Coralogix UI. Separate multiple names with commas
name	The tag name. Omit it and Coralogix derives one from the GitLab payload's project.name and object_attributes.ref fields. See pipeline events

3.

Add the secret token

Enter your API key in Secret Token, below the URL. This field is required. GitLab sends it in the X-Gitlab-Token header, and Coralogix rejects requests without it.

4.

Trigger on pipeline events

Under Trigger, select Pipeline events, then select Save changes.

Shows the trigger that fires a version tag each time a pipeline's status changes.

Send deployment events

Send each deployment to the Coralogix ops events API as well, and it appears as an event marker on your APM charts, so you can line a latency or error-rate change up with the pipeline that caused it.

What you need

• A Send Your Data API key with the OpsEvents role preset. The ops events API rejects any other key type or preset, including the CICDIntegration key used for version tags, with 403 Forbidden.
• The ops events endpoint for your Coralogix domain. Use the domain selector at the top of this page to resolve it: https://api./v1/ops-events
• The service name and environment exactly as they appear in APM. They must equal the service.name and deployment.environment.name resource attributes your service reports. An event that matches no service is still stored, but appears only under All events.

Add the event to your deploy job

Store the API key as a masked CI/CD variable named CX_OPS_EVENTS_API_KEY, then add an after_script to your deploy job. after_script runs whether the job succeeds or fails, and CI_JOB_STATUS carries the result. The job image must include curl.

deploy-production:
  stage: deploy
  environment: production
  variables:
    SERVICE_NAME: <service_name>
  script:
    - ./deploy.sh
  after_script:
    - |
      case "$CI_JOB_STATUS" in
        success) STATUS=PIPELINE_RESULT_STATUS_SUCCESS ;;
        canceled) STATUS=PIPELINE_RESULT_STATUS_CANCELLATION ;;
        *) STATUS=PIPELINE_RESULT_STATUS_FAILURE ;;
      esac
      if [ -n "$CI_COMMIT_TAG" ]; then REF_TYPE=VCS_REF_TYPE_TAG; else REF_TYPE=VCS_REF_TYPE_BRANCH; fi
      curl -sS --fail-with-body -X POST 'https://api.eu2.coralogix.com/v1/ops-events' \
        -H "Authorization: Bearer $CX_OPS_EVENTS_API_KEY" \
        -H 'Content-Type: application/json' \
        --data-binary @- <<EOF
      {
        "opsEvent": {
          "timestamp": "$(date -u +%Y-%m-%dT%H:%M:%SZ)",
          "description": "$SERVICE_NAME $CI_COMMIT_SHORT_SHA deployed to $CI_ENVIRONMENT_NAME",
          "attributes": {
            "service": { "name": "$SERVICE_NAME" },
            "environment": "$CI_ENVIRONMENT_NAME"
          },
          "cdEvent": {
            "system": "CD_SYSTEM_GITLAB",
            "pipeline": {
              "name": "$CI_PROJECT_PATH",
              "run": { "id": "$CI_PIPELINE_ID", "url": "$CI_PIPELINE_URL" },
              "result": { "status": "$STATUS" },
              "task": { "name": "$CI_JOB_NAME", "type": "PIPELINE_TASK_TYPE_DEPLOY" }
            },
            "vcs": {
              "system": "VCS_SYSTEM_GITLAB",
              "type": "$REF_TYPE",
              "repository": { "name": "$CI_PROJECT_PATH", "url": "$CI_PROJECT_URL" },
              "ref": { "head": { "name": "$CI_COMMIT_REF_NAME", "revision": "$CI_COMMIT_SHA" } }
            }
          }
        }
      }
      EOF

Replace <service_name> with the service name from APM. The example takes the environment from the job's environment keyword, so set that to the environment name APM shows, or replace $CI_ENVIRONMENT_NAME with a literal value.

A successful request returns the server-generated event id. The marker then appears on the service's APM charts; see Event markers for how to show it and for the full field reference. The API rejects a timestamp more than 24 hours from the time the request is received, so send the event from the pipeline as it runs rather than backfilling.
