Using Coralogix to Gain Insights From Your FortiGate Logs

  • Shuki Shahrabany
  • April 28, 2021
fortigate logs

FortiGate, a next-generation firewall from IT Cyber Security leaders Fortinet, provides the ultimate threat protection for businesses of all sizes. FortiGate helps you understand what is happening on your network, and informs you about certain network activities, such as the detection of a virus, a visit to an invalid website, an intrusion, a failed login attempt, and myriad others.

This post will show you how Coralogix can provide analytics and insights for your FortiGate logs.

FortiGate Logs

FortiGate log events types are various and are divided into types (Traffic Logs, Event Logs, Security Logs, etc…) and subtypes per each type, you can view full documentation here. You may notice that the FortiGate logs are structured in a Syslog format, with multiple key/value pairs forming textual logs.

First, you will need to parse the data into a JSON log format to enjoy the full extent of the Coralogix capabilities and features and eventually, using Coralogix alerts and dashboards, instantly diagnose problems, spot potential security threats, and get a real-time notification on any event that you might want to observe. Ultimately, this offers a better monitoring experience and more capabilities from your data with minimum effort.

There are two ways to parse the FortiGate logs, either it is done on the integration side or at the 3rd party logging solution you are using if it allows a parsing engine. If you are using Coralogix as your logging solution you can use our advanced parsing engine to create series of rules within the same parsing group to eventually form a JSON object from the key/value pairs text logs. Let us review both options.

Via Logstash

In your logstash.conf add the following KV filter:

    filter {
      kv {
        trim_value => "\""
        value_split => "="
        allow_duplicate_values => false
      }
    }

Note that the arguments “value_split” and  “allow_duplicate_values” are not mandatory and by default, they are set with the values I am presenting here, I only added them for reference.

Sample log
date=2019-05-10 time=11:37:47 logid="0000000013" type="traffic" subtype="forward" level="notice" vd="vdom1" eventtime=1557513467369913239 srcip=10.1.100.11 srcport=58012 srcintf="port12" srcintfrole="undefined" dstip=23.59.154.35 dstport=80 dstintf="port11" dstintfrole="undefined" srcuuid="ae28f494-5735-51e9-f247-d1d2ce663f4b" dstuuid="ae28f494-5735-51e9-f247-d1d2ce663f4b" poluuid="ccb269e0-5735-51e9-a218-a397dd08b7eb" sessionid=105048 proto=6 action="close" policyid=1 policytype="policy" service="HTTP" dstcountry="Canada" srccountry="Reserved" trandisp="snat" transip=172.16.200.2 transport=58012 appid=34050 app="HTTP.BROWSER_Firefox" appcat="Web.Client" apprisk="elevated" applist="g-default" duration=116 sentbyte=1188 rcvdbyte=1224 sentpkt=17 rcvdpkt=16 utmaction="allow" countapp=1 osname="Ubuntu" mastersrcmac="a2:e9:00:ec:40:01" srcmac="a2:e9:00:ec:40:01" srcserver=0 utmref=65500-742
Output
{
	"date": "2019-05-10",
	"time": "11:37:47",
	"logid": "0000000013",
	"type": "traffic",
	"subtype": "forward",
	"level": "notice",
	"vd": "vdom1",
	"eventtime": "1557513467369913239",
	"srcip": "10.1.100.11",
	"srcport": "58012",
	"srcintf": "port12",
	"srcintfrole": "undefined",
	"dstip": "23.59.154.35",
	"dstport": "80",
	"dstintf": "port11",
	"dstintfrole": "undefined",
	"srcuuid": "ae28f494-5735-51e9-f247-d1d2ce663f4b",
	"dstuuid": "ae28f494-5735-51e9-f247-d1d2ce663f4b",
	"poluuid": "ccb269e0-5735-51e9-a218-a397dd08b7eb",
	"sessionid": "105048",
	"proto": "6",
	"action": "close",
	"policyid": "1",
	"policytype": "policy",
	"service": "HTTP",
	"dstcountry": "Canada",
	"srccountry": "Reserved",
	"trandisp": "snat",
	"transip": "172.16.200.2",
	"transport": "58012",
	"appid": "34050",
	"app": "HTTP.BROWSER_Firefox",
	"appcat": "Web.Client",
	"apprisk": "elevated",
	"applist": "g-default",
	"duration": "116",
	"sentbyte": "1188",
	"rcvdbyte": "1224",
	"sentpkt": "17",
	"rcvdpkt": "16",
	"utmaction": "allow",
	"countapp": "1",
	"osname": "Ubuntu",
	"mastersrcmac": "a2:e9:00:ec:40:01",
	"srcmac": "a2:e9:00:ec:40:01",
	"srcserver": "0",
	"utmref": "65500-742"
}

Via Coralogix

In settings –> Rules (available only for account admins) create a new group of rules with the following 3 REGEX-based replace rules. These rules should be applied consecutively (with an AND between them) on the FortiGate logs in order to format. Don’t forget to add a rule matcher to enable the parsing to take place only on your FortiGate data. Here are the rules:

  1. Regex pattern
    ([a-z0-9\_\-]+)=(?:\")([^"]+)(?:\")

    Replace pattern

    "$1":"$2",
  2. Regex pattern
    ([a-z0-9\_\-]+)=([0-9\.\-\:]+|N\/A)(?: |$)

    Replace pattern

    "$1":"$2",
  3. Regex pattern
    (.*),

    Replace pattern

    {$1}

For the same sample log above the result will be similar and the log entry you will have in Coralogix will be parsed as JSON.

FortiGate Dashboards

Here is an example FortiGate firewall Overview dashboard we created using FortiGate data. The options are practically limitless and you may create any visualization you can think of as long as your logs contain that data you want to visualize. For more information on using Kibana, please visit our tutorial.

FortiGate firewall Overview

FortiGate Alerts

Coralogix User-defined alerts enable you to easily create any alert you have in mind, using complex queries and various conditions heuristics, thus being more proactive with your FortiGate firewall data and be notified in real-time with potential system threats, issues, etc… Here are some examples of alerts we created using traditional FortiGate data.

The alert Condition can be customized to your pleasing and how it fits or satisfies your needs.



Alert name Description Alert Type Query Alert condition
FortiGate – new country deny action New denied source ip New Value action:deny Notify on new value in the last 12H
FortiGate – more than usual deny action More than usual access attempts with action denied Standard action:deny More than usual
FortiGate – elevated risk ratio more than 30% High apprisk ratio Ratio Q1 – apprisk:(elevated OR critical OR high)
Q2 – _exists_:apprisk
Q1/Q2>0.3 in 30 min
FortiGate – unscanned transactions 2x compared to the previous hour double of unscanned transactions comparing to previous hour Time relative appcat:unscanned current/an hour ago ration greater than 2x
FortiGate – critical risk from multiple countries alert if more than 3 unique destination countries with high/critical risk Unique count apprisk:(high OR critical) Over 3 unique dst countries in last 10 min

To avoid noise from these Alerts, Coralogix added a utility to allow you to simulate how the alert would behave. At the end of the alert, click verify Alert.

Need More Help with FortiGate or any other log data? Click on the chat icon on the bottom right corner for quick advice from our logging experts.
